Two Year Guarantee on this item

Please see product spechere

Condition: Brand new without box, box may be marked from storage

10 metre range from a 45mm diameter radiating face operating on solids and liquids. 50kHz frequency 10 beam angle

dB Transducer Series

Non-contacting ultrasonic transducers for level measurement

The Pulsar dB Transducer Series are ultrasonic transducers that can measure level in a wide range of liquids, powders and solids as well as open channel flow applications. The dB Transducers have a compact, low power transducer design that can be I.S. certified and uses standard interconnecting cables, yet produces extremely high acoustic power to give exceptional results in a wide variety of challenging situations. All transducers also have flammable atmosphere approval as standard. dB Transducers can be teamed with any of Pulsar’s control units to create the perfect solution for your application.

Applications:

• liquids, powders and solids level measurement
• open channel flow measurement
• corrosive applications
• dry dusty environments
• risk of submergence applications

DATA APPLICABLE TO ALL TRANSDUCERS: Operating temperature range: -40C to +90C (-40F to +194F) (dB3: -30C to +90C) (Hazardous area versions +75C/+167F max) Hazardous area approval:/ Standard ATEX (Ex II 2GD EEx m II T6 Tamb=-40C to +75C) or optional (Ex II 1GD EEx ia IIC T6 Tamb=-40C to +75C). (FM/FMC approved available) N.B. not dB50 IP Rating: IP68 to BS En 60068-2-17: 1995 and BS EN 60529 (Nema 6P available) Integral cable lenth: Standard 5, 10, 20 or 30m CE Approvals: See EC Declaration of Conformity in the manual Bump, shock and vibration: BS EN 60068-2-29, BS EN 60068-2-27 and BS EN 60068-2-6 HOUSING DETAILS: dB3: Valox 357 PBT
78mm/3.07in dia x 115mm/4.52in
BSP or 1″NPT mounting connection dB6: Valox 357 PBT
86mm/3.39in dia x 104mm/4.09in
BSP or 1″NPT mounting connection dB10: Valox 357 PBT
86mm/3.39in dia x 104mm/4.09in
BSP or 1″NPT mounting connection dB15: Valox 357 PBT
86mm/3.39in dia x 122mm/4.8in
BSP or 1″NPT mounting connection dB25: Valox 357 PBT
105mm/4.13in dia x 142mm/5.59in
BSP or 1″NPT mounting connection dB40 & dB50: Valox 357 PBT
205mm/8.07in dia x 223mm/8.77in
BSP or 1″NPT mounting connection OPTIONAL FLANGES – All have PTFE full face on process side: dB6: ANSI 2″, 3″, 4″, 6″ 8″, DIN 50, 80, 100, 150, 200, Sanitary 3″ dB10: ANSI 2″, 3″, 4″, 6″ 8″, DIN 50, 80, 100, 150, 200, Sanitary 3″ dB15: ANSI 3″, 4″, 6″ 8″, DIN 80, 100, 150, 200 OPTIONS – See alsodB Transducer Accessories: Facings: Closed cell soft foam for increased power in dry dusty environments, PTFE standard on all flanged transducers for chemical compatibility Submergence shield: For continuous operation in applications at risk of submergence Beam aiming kit: Recommended for easy transducer aiming in solids applications
