Materials:
Body: nickel-plated brass / PA 66, sleeve: PA 66 (M 3: nickel-plated steel / PA66), seal: NBR, holding claws: stainless steel, cartridge: Zinc-plated ZnDC (only silicone-free seals and lubricants are used during assembly)

Temperature range:
-20 to +80 C

Operating pressure:
-0,95 to 20 bar

Media:
oiled and unoiled compressed air, neutral gases and water (water up to max 60 C may be used only after we have approved the performance specifications).

Advantages:
Wide variety of products,
extremely tight due to lip seal,
available with conical, PTFE-coated thread or with cylindrical thread and captive O-ring
